Atlantech Ultrasonic Flow Meter

Name: Atlantech Ultrasonic Flow Meter
Brand: SAMA INDUSTRIAL SOLUTIONS
Price: 25000.0 INR
Availability: InStock

Price 25000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Atlantech Ultrasonic Flow Meter Specification

Mounting
Flanged

Equipment Type
Ultrasonic Flow Meter

Dimension (L*W*H)
Depends on diameter (customized)

Color
Blue

Response Time
1s

Diameter
DN25 - DN600

Sensitivity
High

Length
Depends on model size

Measurement Range
0.1 - 10 m/s (flow velocity)

Frequency
Transducer Frequency: 1MHz/2MHz

Current Range
4-20mA

Resolution
0.001 m/s

Storage Temperature
-40C to +85C

Connecting Type
Flange

Velocity Range
0.1 - 10 m/s

Connectivity Type
Wired

Connector
Cable Gland

Output
4-20mA, Pulse

Signal Type
Analog, Digital

Housing Material
Aluminum alloy

Operating Temperature
-20C to +60C

Humidity %
85% RH

Pressure Range
1.6MPa

Process Connection
Flanged

Temperature Range
-20C to +60C

Measuring Units
m3/h, L/min, etc.

Model
Atlantech Ultrasonic Flow Meter

Language
English

Application Media
Liquid (Water, Oil, Chemicals, etc.)

Stability
0.1% of full scale/year

Protection
IP65 / IP68 (optional)

Flow Rate
0.1 m3/h - 10,000 m3/h

Sensor Type
Dual-channel Ultrasonic

Input
24V DC/AC

Material
Stainless Steel / Cast Iron

Power Supply
24V DC

Power Consumption
<2W

Accuracy
1% of reading

Display Type
Digital LCD

Range
0.1 - 10 m/s

Repeatability
0.2%

Compliance
CE Certified

Install Method
Inline, clamp-on option

Electrode Material
Stainless steel

Communication Interface
RS485 Modbus

Data Logging
Optional internal memory

Transducer Material
Titanium/SS (application-based)

Power Frequency Immunity
>30V/m

Environmental Protection
Suitable for outdoor/indoor application

Operating Pressure
Up to 1.6 MPa

Atlantech Ultrasonic Flow Meter Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
5-7 Days

About Atlantech Ultrasonic Flow Meter

The Atlantech Ultrasonic Flow Meter is a non-intrusive, high-accuracy device designed to measure liquid velocity and flow rates using ultrasonic sound waves without interrupting system operations

Exceptional Accuracy and Versatility

Offering an impressive accuracy of 1% of reading and repeatability of 0.2%, the Atlantech Ultrasonic Flow Meter ensures dependable performance across a wide velocity range of 0.1-10 m/s. This flow meter is suitable for measuring liquids such as water, oil, and chemicals, making it highly versatile for various industrial, municipal, or commercial applications. Its robust construction and advanced technology guarantee reliable results, even in demanding conditions.

Flexible Installation and Operation

The Atlantech Flow Meter is designed for straightforward integration with its inline and clamp-on options, accommodating diverse pipe systems. Supporting flanged process connections and a wide diameter range (DN25-DN600), it suits both small and large-scale operations. The device operates efficiently within a temperature span of -20C to +60C and handles pressures up to 1.6 MPa, ensuring adaptability for both indoor and outdoor environments.

Advanced Connectivity and Data Management

Equipped with RS485 Modbus communication, analog and digital outputs, and optional internal memory for data logging, the Atlantech Flow Meter meets modern data and monitoring needs. The user-friendly digital LCD presents flow readings clearly, while outputs including 4-20mA and pulse signals facilitate easy integration with control systems. Certified for electromagnetic immunity and electrical protection, this meter excels in reliability and convenience.

FAQ's of Atlantech Ultrasonic Flow Meter:

Q: How is the Atlantech Ultrasonic Flow Meter installed?

A: The Atlantech Ultrasonic Flow Meter supports both inline and clamp-on installation options. Inline installation requires direct integration with the pipeline using flanged connections, while clamp-on methods allow mounting the transducer externally on the pipe. Both methods are suitable for pipes of diameter DN25 to DN600, providing flexibility for various application needs.

Q: What types of liquids can this flow meter measure?

A: This flow meter is designed to measure a wide range of liquids, including water, oils, and various chemical solutions. Its dual-channel ultrasonic sensor and high sensitivity allow it to deliver accurate results regardless of the fluid's composition, provided that the fluid is relatively homogeneous and free of excessive air bubbles or suspended solids.

Q: Where can the Atlantech Ultrasonic Flow Meter be used?

A: The device is suitable for both indoor and outdoor installations, thanks to its robust IP65 or optional IP68 environmental protection rating. Its durable materials, such as stainless steel and titanium, along with an operational temperature range of -20C to +60C, make it ideal for a variety of industrial and commercial settings.

Q: What data communication and output options are available?

A: The meter features a communication interface with RS485 Modbus, enabling seamless integration with control and monitoring systems. It also provides both analog (4-20mA) and digital pulse outputs, and has an optional internal memory for on-board data logging, enhancing its data management capabilities.

Q: When is internal data logging beneficial for users?

A: Internal data logging is particularly advantageous for applications that require historical flow data to be reviewed or analyzed without constant supervision. It allows users to store and later retrieve flow measurements, facilitating maintenance, troubleshooting, and performance assessment of the fluid system.

Q: What are the main benefits of using this ultrasonic flow meter?

A: The meter offers high measurement accuracy (1% of reading), excellent repeatability (0.2%), ease of installation, and robust construction suitable for challenging environments. Additional advantages include low power consumption, comprehensive output options, data logging, and assured regulatory compliance via CE certification.
